| Model | YTD-4color |
| Material feeding width | 600mm 800mm 1000mm 1200mm 1400mm |
| Max Printing Width | 560mm 760mm 960mm 1160mm 1360mm |
| Colors | 4colors |
| Material | Pe.pet.bopp.pvc.nylon.non-woven.breathable film |
| Thickness of plate | 1.14mm.1.7mm 2.28mm.2.84mm. 3.94mm Customized is available |
| Printing length | Standard is 400mm, Customized is available from 380-800mm |
| Maximum printing speed | 250m/min |
| Register precision | longitudinal registration ±0.15mm Transversal registration ±0.15mm |
| Structure type | Central impression（central drum） |
| Gear module | 1.5mm |
| Heating method | Electricity heating |
| Max. oven temp. | Max. 80℃ (room temp. 20℃） |
| Unwinder/rewinder paper | core 3＂ |
| Max. unwinder/rewinder dia. | 1000mm |
| Suitable Ink | Water based ink / Solvent ink |
Frame and web running:
1.The frame is made of alloy cast iron with high strength and lower stress. It is
casted by resin sand process and treated by vibration aging.
2.Integral type guide roller structure.
3.Assembled modularization in design.
4.Frame thickness 100mm
5.Guide roller Φ100mm (Surface anodic oxidation treatment)
Here is some detail picture below.Hope can make you know more about our machine
PRICE: 8,200USD FOB NINGBO PORT
1. Terms of payment: pay 30% for deposit by T/T before arrange manufacture, the balance paid before shipment by T/T.
2.Delivery time: 30 days after received the 30% down payment.
3. Packaging: shrink film.
4. Debugging: The sellers don’t provide the debugging. We will supply the video.(If need the debugging, the buyer should pay for the worker, also the air ticket and hotel)
5. Document:B/L,packing list, invoice,CO.
6. Guarantee: 1 year. First year maintain the main electric part free, but the buyer will charge for express fees. From second year, the buyer will change maintain fees and express fees.
7.value day: 60 days
