The price including :
- Single doctor blade with auto ink pump* 6pcs
- Plate roller 40cm *4pcs.
- Ceramic Anilox Roller (80–1000LPI) * 6pcs
- EPC (Ultrasonic web guide) *1pcs
- Air shaft * 2pcs
- Auto tension control*2sets
- Ink pump *6pcs
- Single rewinding and unwinding
- Pneumatic material loading for rewind and unwind
- Chamber doctor blade 6pcs
- Video camera 1 pcs
- Roller barrow
| Technical Specification | |
| Model | Honor |
| Material Feeding Width | 1200mm |
| Max Printing Width | 1160mm |
| Colors | 6colors |
| Material | PAPER. PVC.OPP.PE.BOPP.PE.NY.PET. |
| Thickness of plate | 1.14mm.1.7mm 2.28mm.2.84mm. 3.94mm Customized is available |
| Printing length | Standard is 400mm，Customized is available from 300- 1000mm |
| Printing speed | 80m/min-120m/min |
| Register precision | ±0.3mm |
| Heating method | Electricity heating |
| Max. unwind/ rewind dia. | 1000mm |
| Part 1 Unwinding And Rewinding Unit | ||||
| SN | Item | Qty | Specification | Picture |
| 1 | Air shaft | 2SET | Roller Dia. 76mm | |
| 2 | Tension Control | 2SETS | 1. Magnetic power tension10KG 2.2sets for unwind and rewind | |
| 3 | Web guide | 1SET | 1. Automatic EPC system 2. After manual adjustment, change to automatic mode | |
| Part 2 Printing Unit | ||||
| S N | Item | Qty | Specification | Picture |
| Transmission | 1 SET | Driven by a belt,high accuracy | ||
| 2 | Plate roller | 6 Pcs | 1. Standard 400mm for machine 2. Circumference: 280-1000mm 3. Can be customized. | |
| 3 | Ceramic anilox roller | 6 Pcs | 1. Transfer ink evenly 2. Range: 300-1000 lines/in | |
| 4 | Single doctor blade | 6 Pcs | 1. Made from Aluminum alloy 2. Fast speed ,not spill the ink 3. Special for high speed printing machine 4. Prevent ink splashing | |
| 5 | Ink pump | 6 Pcs | 1.Automatic circle system | |
| 6 | operate panel | 1SET | Switching and various parameter settings |
| Part 3 Drying Unit | ||||
| SN | Item | Qty | Specification | Picture |
| 1 | Top main oven | 1SET | 1. Use hot air drying, intelligent constant temp control. 2. Consistant 2 sets oven by independent 3. Total power:20KW | |
| 2 | Color group oven | 3SET | 1. Installed after the printing units | |
| Optional device need pay extra | ||||||
| SN | Item | Qty | Specification | Picture | ||
| 1 | Corona | 1SET | Make the surface of films have stronger adhesion | |||
| 2 | Anilox ultrasonic cleaning machine | 1SET | Using ultrasonic vibration to peel off and clean the ink on the surface of the anilox roller | |||
| 3 | Plate Mounting Machine with Camera | 1SET | Mainly used in flexograhic printing machine to complete plate mounting operation | |||
| 4 | hydraulic loading | 1SET | Max 1 ton | |||
| 5 | Video inspection | 1SET | Check the printing quality on the video screen | |
| 7 | Chamber doctor blade | 1 Pcs | 1. Made from Aluminum alloy 2. Fast speed ,not spill the ink 3. Close type to reduce solvent volatilization 4. Teflon coating surface treatment | |
| 8 | Joist barrow | 1 Pcs | 1.It’s easy to lift the materials |
