The Price Including :
- Single doctor blade with auto ink pump* 8pcs
- Plate roller 40cm *8
- Ceramic Anilox Roller (80–1000LPI) * 8pcs
- EPC (Ultrasonic web guide) *1pcs
- Air shaft * 2pcs
- Auto tension control*2sets
- Ink pump *8pcs
- Single rewinding and unwinding
- Pneumatic material loading for rewind and unwind
| Technical Specification | |
| Model | Honor |
| Material Feeding Width | 1200mm |
| Max Printing Width | 1160mm |
| Colors | 8colors |
| Material | PAPER. PVC.OPP.PE.BOPP.PE.NY.PET. |
| Thickness of plate | 1.14mm.1.7mm 2.28mm.2.84mm. 3.94mm Customized is available |
| Printing length | Standard is 400mm，Customized is available from 300- 1000mm |
| Printing speed | 80m/min-120m/min |
| Register precision | ±0.3mm |
| Heating method | Electricity heating |
| Max. unwind/rewind dia. | 1000mm |
| Part 1 Unwinding And Rewinding Unit | ||||
| SN | Item | Qty | Specification | Picture |
| 1 | Air shaft | 2SET | Roller Dia. 76mm | |
| 2 | Tension Control | 2SETS | 1. Magnetic power tension10KG 2.2sets for unwind and rewind | |
| 3 | Web guide | 1SET | 1. Automatic EPC system 2. After manual adjustment, change to automatic mode | |
| Optional device need pay extra | ||||||
| SN | Item | Qty | Specification | Picture | ||
| 1 | Corona | 1SET | Make the surface of films have stronger adhesion | |||
| 2 | Anilox ultrasonic cleaning machine | 1SET | Using ultrasonic vibration to peel off and clean the ink on the surface of the anilox roller | |||
| 3 | Plate Mounting Machine with Camera | 1SET | Mainly used in flexographic printing machine to complete plate mounting operation | |||
| 4 | hydraulic loading | 1SET | Max 1 ton | |||
| Part 3 Drying Unit | ||||
| SN | Item | Qty | Specification | Picture |
| 1 | Top main oven | 1SET | 1. Use hot air drying, intelligent constant temp control. 2. Consistent 2 sets oven by independent 3. Total power:20KW | |
| 2 | Color group oven | 8SET | 1. Return air oven, blowing at one end and sucking at the other, highly efficient and energy-saving 2. The ink will not penetrate into the oven, which is safe | |
| 4 | Single doctor blade | 8 Pcs | 1. Made from Aluminum alloy 2. Fast speed, not spill the ink 3. Special for high-speed printing machine 4. Prevent ink splashing | |
| 5 | Ink pump | 8 Pcs | 1.Automatic circle system | |
| 6 | operate panel | 1SET | Switching and various parameter settings |
| Part 2 Printing Unit | ||||
| SN | Item | Qty | Specification | Picture |
| 1 | Transmission | 1 SET | Driven by a belt, high accuracy | |
| 2 | Plate roller | 8 Pcs | 1. Standard 400mm for machine 2. Circumference: 280-1000mm 3. Can be customized. | |
| 3 | Ceramic anilox roller | 8 Pcs | 1. Transfer ink evenly 2. Range: 300-1000 lines/in | |
| 4 | Single doctor blade | 8 Pcs | 1. Made from Aluminum alloy 2. Fast speed, not spill the ink 3. Special for high-speed printing machine 4. Prevent ink splashing | |
| 5 | Ink pump | 8 Pcs | 1.Automatic circle system | |
| 6 | operate panel | 1SET | Switching and various parameter settings |
| Part 3 Drying Unit | ||||
| SN | Item | Qty | Specification | Picture |
| 1 | Top main oven | 1SET | 1. Use hot air drying, intelligent constant temp control. 2. Consistent 2 sets oven by independent 3. Total power:20KW | |
| 2 | Color group oven | 8SET | 1. Return air oven, blowing at one end and sucking at the other, highly efficient and energy-saving 2. The ink will not penetrate into the oven, which is safe | |
| Optional device need pay extra | ||||||
| SN | Item | Qty | Specification | Picture | ||
| 1 | Corona | 1SET | Make the surface of films have stronger adhesion | |||
| 2 | Anilox ultrasonic cleaning machine | 1SET | Using ultrasonic vibration to peel off and clean the ink on the surface of the anilox roller | |||
| 3 | Plate Mounting Machine with Camera | 1SET | Mainly used in flexographic printing machine to complete plate mounting operation | |||
| 4 | hydraulic loading | 1SET | Max 1 ton | |||
| 5 | Video inspection | 1SET | Check the printing quality on the video screen | |
| 7 | Chamber doctor blade | 1 Pcs | 1. Made from Aluminum alloy 2. Fast speed, not spill the ink 3. Close type to reduce solvent volatilization 4. Teflon coating surface treatment | |
| 8 | Joist barrow | 1 Pcs | 1.It’s easy to lift the materials |
| Comparison of flexor and gravure printing | |||
| NO | Item | LISHG flexo printing machine | Gravure printing machine |
| 1 | Land area | Occupies little space | Occupies big space |
| 2 | ink | Environmentally friendly | No Environmentally |
| 3 | Cost | Low | high |
| 4 | Plate | Low cost | High cost |
| 5 | Printing cylinders | reuse | One time |
| 6 | Volume of ink | Less | More |
| 7 | Power | Low | High |
| 8 | Plate loss rate | Low | High |
| 9 | Ink delivery method | Chamber doctor blade，the Ink is not easy to evaporate | The ink is exposed and easily evaporates, causing waste |
| 11 | material | Many types | Less types |
| 12 | Machine clean | Easy | Hard |
| 13 | Application field | widely | Narrow |
Product Application:
Max width of material: 1200mm
Printing color: 6colors
Max printing width: 1160mm
Machinery mechanical speed: 420m/min
Max. Speed of Material Printing: 350-400m/min, according to different material and print design
Material: Paper, PE, PET, BOPP, PVC
Max. Printing Length (Repeat): 400mm-800mm
Machine power: 380V, 3PH, 50HZ/60HZ
