Machine Details :
| SPECIFICATION | ABA45X50X900 | |
| FEATURE | SUITABLE MATERIAL | HDPE, LDPE,LLDPE |
| LAYER NUMBER | 3-ABA | |
| FILM THICKNESS | HD: 0.008-0.06MM | |
| MAX OUTPUT | 160KG/H | |
| MAX FILM WIDTH | 800MM | |
| EXTRUSION UNIT | SCREW DIAMETER | Φ45X50 |
| SCREW L/D RATIO | 32/1 | |
| SCREW MATERIAL | BIMETALLIC | |
| BARREL THERMO CONTROL | 3X2 |
| BARREL COOLING FAN | 200WX3X2 | |
| SCREEN CHANGER | STANDARD | |
| DRIVING MOTOR | 15KW X 22KW SIEMENS | |
| GEARBOX | #146*146 SG | |
| DIE HEAD UNIT | DIE | HDPEABAΦ60/80/100MM |
| DIE TYPE | FIXED DIE | |
| AIR RING | DUAL LIP ITALY DESIGN | |
| AIR BLOWER | 5.5KW | |
| TAKE UP UNIT | BUBBLE CAGE MATERIAL | ALUMINUM |
| TOP NIP MATERIAL | WOODEN | |
| BANANA ROLLER | 1PCS | |
| TAKE UP ROLL MATERIAL | HIGH TEMP RUBBER | |
| TAKE-UP ROLLER LENGTH | 900MM | |
| GUSSET | INCLUDED | |
| TAKE-UP MOTOR | 1.5KW GEAR MOTOR | |
| TAKE-UP SPEED | 10-80M/MIN | |
| PINCH PATTERN | PNEUMATIC | |
| WINDING UNIT | WINDING TYPE | SINGLE MANUAL WINDER |
| WINDING ROLLER LENGTH | 900MM | |
| WINDING SHAFT | AIR SHAFTX2 | |
| BANANA ROLLER | 1PCS | |
| WINDING ROLLER LENGTH | 900MM | |
| MAX DIA.OF WINDED ROLL | 800MM | |
| WINDING MOTOR | TORQUE MOTOR WITH DELTA INVERTER | |
| ELECTRIC BOX | INVERTER | DELTA (Taiwan) |
| TEMPERATURE CONTROL | OMRON （Japan) | |
| CONTACTOR | ABB （Switzerland） | |
| SSR | FOTEK (Taiwan ) |
| OTHERS | CORONA MACHINE | INCLUDED |
| AUTOMATIC MATERIAL LOADER WITH DRYER | INCLUDED | |
| MACHINE HEIGHT | 4.8 METER |
